Corner window with silicon join glass

Finished Product, Work in progress

Today we went on site to glaze some windows we had manufactured earlier.

all western red cedar, and in the pics below you can see corner window with silicon join glass.





Advertisements

Installing the arched windows

Finished Product, Work in progress

My last little post had a picture of arches being made.

here is the photo of one of the windows being installed.

it went almost perfect today, i had the first window out by 8am, and the new ones fit perfectly with no need to adjust or alter.

Random bits n pieces

Work in progress

I’ve been pretty slack posting new bits n pieces up.

too much to do!

new window made basedon old broken one. quite ugly but who are we to decide. it also has pink glass for it.

double glazed cedar lift up windows.

cedar sliding door

sash rails being prepared for assembly. all those round bits on the end become the sash horns. photo’d in black and white for a change

OAK doorframe for a church

Work in progress

My entire last week was spent on a first floor of a hall installing 16 bronze anodise sliding windows.  It was a challenge (4 of us there all week) but in terms of photos, pretty boring.  But this was being made at the factory by my timber lads and when i returned to work I had to photo this and share it.

Solid Oak. roughly 2900 high x 3000 wide. We are making a pair of doors (again solid oak) which when we install the frame will be hung on pivots.

The fixed panels on the sides will be adorned with crosses and other ikons for the church.

Oak doorframe
2900 x 3000 or so. 2 doors on pivot hinges will be made and hung when we install it . for a church in adelaide. the panels on the sides will have crosses and other items

Aluminium Awning Window

Finished Product

We make a fair few of these style aluminium windows.  Commercial frame (101mm x 44.5mm) with an awning sash and lockable whitco chain winder.  Fly screen on inside.

The awning has no hinges or stays, and instead has a hook on the head and a matching hook on the top of the sash.  No moving on this turning point means nothing will wear out and break (as do hinges and non-friction stays after years of use)

Thought id take a photo before delivering it to a job site this morning.

com awning

Box Frame Window

Finished Product

Last week we installed 2 boxframe windows in cedar.  I finally got some time to upload the pics.  All in western red cedar, weights and pulleys box frame. top sash fixed, bottom sash lift up. flyscreen in timber on the outside. Glazed with double glazing with argon gas.

WRC single hung box frame window with double glaze glass. Angled aves and reveals.

WRC single hung box frame window with double glaze glass. Angled aves and reveals.

WRC single hung box frame window with double glaze glass.

WRC single hung box frame window with double glaze glass.

WRC single hung box frame window with double glaze glass.

WRC single hung box frame window with double glaze glass.

Office Partitions

Work in progress

Here is some photos of the office partitions we have set up this morning.  Located in the CBD on a third floor of a building. Glazing will be clear laminate; 6 and 10.38 thickness.  No one is looking forward to lifting the glass up 3 stories.

20150821_092910

Clear Anodise Commertcial aluminium framing. This is for office partitions on a 3rd floor of a building in the adelaide CBD. Ready for glazing.

20150821_093040

Clear Anodise commercial framing with hinged door and stainless steel handle. Egress lock with cylinder on outside. We are making 4 of these frames to make 4 rooms.
